Wall Panels Bulkheads and Linings





A-Catalog Cards                     D-Top Connections
B-Wall Joints                          E-Angle Connection
C-Bottom Connections           F-Doors Joints


Constructional system of partitions and linings characterizes by almost complete prefabrication of elements and mounting profiles. It ensures easy and fast installation, and accommodations of high standard. Accommodations designed in this system meet the requirements of fire protection of all classes and acoustic insulation.

Beside basic partitions and linings we supply also partitions and linings for wet areas.

CONSTRUCTION
The “sandwich” panels used in construction are made from galvanized steel sheets coated with decorative PVC foil. Between steel sheets there is thermal and acoustic core made of mineral wool. Lengthwise edges of board are fastened with a connector and are shaped in such a way that they form “own fastener”. These are also known as progressive style panels. We can also supply “C” clip panels, which are a non‐progressive system and allows for easy assembly and dismounting without disturbing adjacent panels. The completeness of the system lies in the fact that the producer offers bottom and top profiles, multi‐functional corner profiles, which make various joints between walls and wall/ceilings possible. In addition we can supply lining doors, cable casings, window framings, cases for the extinguishers.

FIRE RESISTANCE
  -Basic materials are classified as non‐combustible.
  -Finishing materials (decorative coatings) meet the requirements of international standard in scope of low flame‐spread characteristics. All materials are non‐toxic.
 -Presented wall structures passed international fire test according to SOLAS‐1974 Convection with
amendments and comply with relevant requirements.
  -Wall structure is approved as B0 and B15 by different Classification Societies and National Authorities.
  -Certificates of approvals, materials and approved drawings of mounting joints are submitted on request.

MOUNTING
Mounting of wall panels must be carried out in accordance with a design. Before starting mounting of walls, the places of fixing bottom and top channels shall be marked on the steel deck. Bottom, top channels and fasteners or curtain plates shall be welded to the steel deck. Partition and lining boards are placed in bottom and top channels, which create a self‐supporting construction of walls. Various corner and wall profiles are used for corner joints.

Completing wall structure panels should be mounted in the last sequence of outfitting. The mounting of boards located near doors is done after fixing doors by means of “Omega” profile or two guiding profiles. All additional casing such as: pilers, ducts shall be made of cut‐off panels. All joints of these panels shall be masked by standard or untypical finishing profiles. Visible surfaces of boards and profiles are protected by peel‐off foil during production and assembly. Lukewarm water and soap or ordinary detergent usually removes dirty stains. Never use any abrasive means or scouring powder.

2017年1月4日星期三

A60 Marine Single-Leaf Fireproof Door-Q105ZXS01-11


Zhenjiang Speed Horse provides various of internal and external marine fire doors. The advantages of the fire doors are sound protection, fire protection and weather ability. There are some of the fire doors such as B0,B15 and A60 for internal use and semi-watertight doors A60 for external use. We are the professional Marine door supplier,manufacture,exporter in China and we can supply the door which according to the customer’s specific requirement.

The fire door that we produced always accepted by the different customers such as from Singapore, Indonesia, Russian and European places. We are focus on the quality of products and have a long-term experience for producing the marine door since 2005.

Application of  A60 Marine Single-Leaf Fireproof Door-Q105ZXS01-11:
http://zjspeedhorse.com/34-A60-Marine-Single-Leaf-Fireproof-Door.html

Suitable for accommodations with A60 fireproof and watertight requirement, passed the fire text held by Shanghai Far East Firetesting Center.

Certificate: ABS,CCS,BV and etc.

Advantages:

-Solidly Constructed
-Good Sound protection
-Good  Fire protection
-Good Water Proof
-Competitive Price













2017年1月2日星期一

What are the difference between a Watertight door and Weathertight door?

Watertight Door-that doors which are designed to prevent water from outside. These door are designed to maintain the ship stability which should be involved in a unfortunate accident.

In order to make sure these rules are followed and still remain practical, ships make use of watertight doors below the waterline. These doors are usually constructed by a specialize enclosure maker, then fitted into the ship. These doors "break" the continuity of a structural bulkhead therefore they reduce the strength of that bulkhead. Because of that, they must be engineered to match the bulkhead's strength and therefore watertight doors can look quite bulky and menacing.

There are many types of the door such as Marine quick Action Anti-pressure watertight steel door as I showed before https://zjspeedhorse.blogspot.jp/2016/12/marine-quick-action-watertight-steel.html

Weathertight is lower watertightness compare with the Watertight Door,  Weathertight door is designed to be located on the deck of ship/boat above the waterline, where they can be subject to the adverse weather conditions experience offshore.Weathertight doors are also designed to withstand brief submersion experienced from green seas.

Advantages of the Watertight Door:

-Flood-Protection Barrier
-Normal-Use Commercial or Residential Door
-Allows Easy Access to the Building or Home
-Can be fitted with standard panic hardware
-Standard or custom sizes available
-Easy installation and retrofit
